Red Color 1.5-50mm Thick High Temperature Silicone Foam Sheet With Close Cell

Red Color Silicone Sponge Sheet, Silicone Foam Sheet With Close Cell

This silicone foam sheet is made by an extremely resilient silicone, it displays excellent resistance to heat, weathering, ozone and a wide range of chemicals. It is impervious to UV lighting, non-toxic, chemically inert and retains its property within -60 ~230°C.

Product Features:

Rugged - When silicone is required, silicone sponge parts offer better toughness as compared to silicone foam products.
Wide operating temperature - Silicone sponge has a temperature range of -58°F to 500°F (-50°C to 220°C).
Water sealing - the closed cell structure allows for good water sealing with relatively low compressive forces.
Compression set resistance - Silicone offers excellent compression set resistance (ability to rebound to original thickness), especially at higher temperatures, compared to most rubber material. Low compression set silicone sponges are available for even better performance than general purpose grades.
UV and ozone resistance - Silicone products have excellent UV and ozone resistance due in part to their inorganic backbone. This provides long term performance.

Product Applications:

- Engineering machinery, ironing table, pressing machine

- Electrical and electronic devices, computer, printers

- Automotive, aerospace, garment, and energy industries

- Furnaces, heaters, kitchen utensils, flues, gas appliances

Specifications for close cell silicone sponge sheet:

material: virgin silicone sponge, silicone foam

cell: closed cell

color: dark red, white, grey, black, beige, brown, blue etc.

surface: double impression fabric, smooth

tensile strength: 100-200PSI

hardness: 10, 15, 20, 25, 30, 35, 40+/-5shore A (currently 20-25shore A)

elongation: 100%

density: 0.48-1.00g/cm³

working temperature: -60°C - +220°C(moment 260°C)

thickness: 1.5-50mm

width: 0.1-1.5m(maximum 1.5m@more than 5mm thickness)

length: 0.1-10m

standard size:

1.5-50mm x 1.0m x 10m

1.5-50mm x 1.2m x 10m

5.0-50mm x 1.5m x 10m

10shore A, density 0.48-0.50g/cm3

15shore A, density 0.50-0.55g/cm3

20-25shore A, density 0.60-0.65g/cm3

25-30shore A, density 0.65g/cm3

30-40shore A, density 1.00g/cm3

OEM & customized size are agreed

packing in cartons, rolls, pallets or crates

backing adhesive is agreed of Chinese general glue or USA 3M glue

perforated silicone sponge sheet is 6, 8, 10mm x 0.9m x 1.8m, red, beige, white color

custom size for silicone sponge extrusion, silicone sponge profile, silicone sponge stripe

For more data & information, pls mail to sales@3Arubber.com

When you enquiry, pls confirm the hardness, color, size and quantity
